dual color led panel light

FOB Reference Price:Get Latest Price
US $166-210 / Piece | 1 Piece/Pieces (Min. Order)
Supply Ability:
2000 Piece/Pieces per Month
Report Suspicious Activity
Quick Details
Item Type:
Video Lights
Input Voltage(V):
AC90-240V, 50/60Hz
Lamp Power(W):
Lamp Luminous Flux(lm):
Lamp Luminous Efficiency(lm/w):
CRI (Ra>):
Color Temperature(CCT):
Warm White
Beam Angle(°):
Working Temperature(℃):
-25 - 45
Working Lifetime(Hour):
IP Rating:
Emitting Color:
Lamp Body Material:
Aluminum Alloy
Base Type:
Light Source:
Light sources:
805pcs 0.5W high CRI and high brightness LED bead chips
from warm white to cold white
Beam angle:
0~100% linear dimmer
Color temperature:
3000k-6000k adjustable
DMX channel:
Control mode:
DMX-512, Demo mode, Manual
Control panel:
LCD display + 4 buttons
Packaging & Delivery
Packaging Details
carton board box, flight case is option
Delivery Time
3-15days, based on the quantity
Product Description

dual color led panel light

High CRI more than 95 LED Bi color soft film broadcasting light

Product details

Light sources805pcs 0.5W high CRI and high brightness LED bead chips
Colorfrom warm white to cold white
Beam angle120degree
Dimmer0~100% linear dimmer
Color temperature3000k-6000k adjustable
DMX channel4CH/5CH
Control modeDMX-512, Demo mode, Manual
Control panelLCD display + 4 buttons
Product Keywords dual color led panel light,double color temperature LED vedio camera light,dmx led studio lights

High CRI Ra>95;
High Brightness;
Bi color: color temperature from 3200K-6000K;
Body slim, weight light, easy installation.

•This light equips two color temperature high cri and brightness led chips, used vangaa linear dimmer technology, to realize the product can meet the strict request when the radio and television shooting. No flicker, smooth linear dimmer, no drawing line when filming. The light is very suitable for large-scale tv station, studio, multi-function room and other video places.


•The light’s lighting function is controlled by DMX-512, very convenient;

•Using bead LED chips, pure color temperature, can realize 0-100% dimmer;

•The light body adopts outside frame design, the modeling is beautiful, installation very convenient, safe and reliable.

Technical Specifications

Light Sources

•LED: 805pcs 0.5W high CRI and high brightness LED bead chips

•Lifespan: 50,000hours

•Color: from warm white to cold white


•Beam angle: 120degree

•Dimmer: 0~100% linear dimmer

Light Output

•CRI: Ra≥95

•Color temperature: 3000k-6000k adjustable


•DMX channel: 4CH/5CH

•Control mode: DMX-512, Demo mode, Manual

•Control panel: LCD display + 4 buttons

Power Supply

•Related voltage: AC100V-240V, 50/60Hz

•Related power: 200W


•Body dimension: D555*W265*H106mm

•Net weight: 6kg

•Shell color: black

•Housing material: aluminum alloy

Working Environment

•Working temperature: -25-40℃

•Cooling: aluminum radiator and light body

•Protection rating: IP20

Spare Parts

•Cable: 1set DMX in and DMX out signal cable,  and 1set Power in and Power out power cable with plug [standard configuration]

•Light visor: 1pc light visor [optional configuration]


•Carton board box package size: 650*430*260mm(1pc/carton) [need confirm]

•N.W/G.W/V.W: 6kg/8kg/15kg

•Flight case package size: 900*1100*400mm(10pc/case)  [need confirm]

•N.W/G.W: 95kg/125kg

Selling Maintain Spare Parts List

•Switching power supply: VG-HTC805C-P

•LED lamp board: VG-HTC805C-L

•Main board: VG-HTC805C-M

•Drive board: VG-HTC805C-D

Quality assurance:

1. VanGaa only equips high quality software, circuit board, light source and other spare parts for all our lighting fixtures;
2. All of our lights have 1 year free quality warrantee, and 4 years cost warrantee, you can purchase the warrantee time when you place order;
3. During the warrantee time, we will bear all the cost to make sure the lights work well.

Packaging & Shipping




 Fast Delivery

Different amount of time will be required for different
Company Information


VanGaa Lighting Co., Limited is an internationally recognized company that focus on energy efficient LED technology for professional studio and stage lighting fixtures.

VanGaa Lighting is established on 2006 in Guangzhou, and we have made up our own factory on 2009 which owns three production lines now. We design and developed the professional studio lighting fixtures, such as the LED Fresnel Spot Light, LED Profile Spot Light, LED Meeting Room Panel Light. The products made by this manufacturer strictly comply with ISO9001:2008, ISO14001:2004, CE and RoSH safety standards.


America,most of Europe countries,Southest of Aisa.

All our products are welcomed by many customers for OEM & ODM.

We are factory supplier and the client can be wholesaler or retailor.

VanGaa, always achieving users' value.


What is the Details of Our LED Fresnel Spot Light?

WHERE can use our soft panel lights?

Studio Room, TV Station, Film Taking, Auditorium, Muilt-function Room, Stage etc

WHICH level of the CRI?

High CRI can reach Ra>92, no flicker

WHAT's the color temperture of them?

3200K/5600K/6500K, or 3000K-6000K

EASY operation or Not?

Yes, very easy for operation, you can use the base useage, or the extension useage.

WHAT's the control panel is?

LCD display+4 buttons, easy operate

HOW about the dimmer?

Linear dimmer, from 0-100%, especial the 0-15%, it's fine dimmer

NOISE is big?

No, it's mute. Although it equips fan, only one imported high quality fan.

How about the COOLING SYSTEM?

body convector, for long time use design

ZOOM is ok or not?

no, the soft panel light is 120degree beam angle

How about the CONTROL MODE?


Can be OUTDOOR use or not?If your outdoor no water or rain, it's ok, the IP rating is 20
How about the BRIGHTNESS?The lumen can reach 11214.7 lm/Φv, welcome to get the reports by email
How about the WEIGHT of the light?The watt is more big, the weight is more heavy, 200W net weight=5.8kg
What's the BODY DIMENSION of it?Please check the dimision photo

What's brand led of this light use?

Famous brand, because of the brand right, we don't show the name here, you can consult our sales manger.

How many watts of every lamp?

0.2W/0.5W LED lamps, the lifespan can reach 50000h.

How about the package of the light?

We use firm carton board box as the outer package, the inner has the shape foam to protect the light. This package can good protect the light during the international transportation. Also you can choose road case package.

What about the after sales service?

When you place the order, our factory will issue the invoice to you, and the light also has the mark of the manufactured time. You can get heart service base on the proof of the purchase order.

How long is the quality warrantee?

You can choose different quality warrantee, the 1st year is included the unit price, you also can purchase 2nd, 3rd years quality warrantee.

How to make sure the quality warrantee?

During the quality warrantee time, if there are any trouble of the light, we will solve the problem freely, send whole spare parts and teach you replace, or send back to repair.

How to purchase the light?

You can send inquiry to our company, or place the order on line, there are the sales manager will provide the heart service to you.

How about the payment?

We accept the payment by T/T, western union, paypal(5% hand charge), alibaba trade assurance etc.
